Fafrees F20 Ultra Electric Motorbike
Prepare for an adrenaline-fueled adventure with the Fafrees F20 ULTRA Electric Motorbike. Boasting a powerful 750W hub motor that peaks at an astonishing 1200W, this bike is designed to deliver thrilling performance on any terrain. The massive 25Ah LG battery ensures extended rides, offering up to 100km on a single charge, while the 20x5.0 fat tyres and double suspension guarantee a smooth and comfortable journey. Whether you're conquering rugged trails or cruising city streets, the F20 ULTRA is built to handle it all with ease.
Equipped with a high-definition LCD display, you can effortlessly monitor speed, battery life, and customise your ride with five-speed settings. The bike's waterproof construction ensures durability in all conditions, and the dual disc brakes provide quick, reliable stopping power. Safety is paramount with front and rear lights, including an integrated rear brake light. The Shimano 7-speed gears offer versatility for various terrains, enhancing battery efficiency. With an extended leather cushion for maximum comfort, the F20 ULTRA is the ultimate choice for those seeking excitement and reliability in an electric motorbike.
Please note that this bike has a 750W motor and should only be ridden on private land.
Plus FREE delivery to UK Mainland when you spend over £500 from Power Drive Bikes today.
What's Included?
- Fafrees F20 Ultra Electric Motorbike
- Battery charger
- Tool kit
- User Manual
-
FREE delivery to UK mainland
-
Manufacturers One year warranty
Hub Drive & Torque Rating
The Fafrees F20 Ultra Electric Motorbike is a rear wheel hub drive bike. This means that the drive motor is positioned in the rear wheel hub of the bike and has specific rider qualities for that type of drive.
Torque Rating - 79 Nm - Provides enhanced power performance
Further information on the drive type benefits of electric bikes is available in ‘A Guide to Electric Bike Motors and Drive Types’ in our guides section of the home page.
Further information on the torque ratings of electric bikes is available in 'A Guide To Understanding Torque in 250W Electric Bike Motors' in our guides section of the home page.
Please note that this bike has a 750W motor and should only be ridden on private land.
User Manual
Please find the Fafrees F20 Ultra Electric Motorbike User Manual Here.
Specifications
This bike is equipped with a throttle.
| Color |
Satin Black/Gunmetal Black/Olive Green |
|
Dimensions
|
Unfolded size |
182*76*103cm |
| Folded size |
// |
| Adjustable height of handlebar |
103cm |
| Adjustable height of seat |
84cm |
| Package size |
151*33*90cm |
| Tire size |
20*5.0 inch |
| Pedal-ground distance |
14cm |
| Recommend rider heights |
160-200cm |
|
Weight
|
Net Weight |
37.5kg |
| Package weight |
47kg |
| Battery weight |
5.5kg |
| Load capacity |
180kg |
|
Material
|
Frame material |
Aluminum alloy |
| Tire Type |
Air tire |
|
Driving
|
Default maximum speed |
25KM/H |
| Adjustable maximum speed |
40KM/H |
| Max range for assisted mode |
120-140KM |
| Max range for pure power |
80-100KM |
| Max climbing Gradability |
20° |
|
Battery
|
Battery type |
Lithium-ion LG cell 21700 |
| Rated voltage (V) |
48V |
| Input voltage (V) |
54.6V |
| Battery capacity (AH/Wh) |
25Ah/1200Wh |
| Undervoltage protection value (V) |
41±1V |
| Overcurrent protection value (A) |
25±1A |
|
Motor
|
Motor rated power (W) |
750W |
| Motor peak output power (W) |
1200W |
| Motor location |
Rear drive |
| Maximum torque (N.m) |
79N.m |
|
Charger
|
Input voltage (V) |
110-240V |
| Output voltage (V) |
54.6V |
| Rated current (A) |
3A |
| charging time |
8h |
|
Damping
|
Fork Type |
Shock fork |
| Fork travel distance |
100mm |
| Type of rear shock |
|
| Rear shock travel distance |
20mm |
|
Display
|
Display type |
LCD Display |
| 6km/h walk assist mode |
Yes |
| Cruise control |
N/A |
| APP control |
N/A |
| PAS level |
0-5 |
| Transmission |
SHIMANO 7S |
| Brake type |
Mechanical disc brakes |
| Folding parts |
N/A |
| Headlight |
Yes |
| Taillight |
Yes |
| Riding mode |
Human/assisted/pure power |
| Operating temperature |
（-20）℃-40℃ |
| Waterproof grade |
IPX5 |
| Package contains |
1 x FAFREES electric bike
1 x Battery charger
1 x Tool kit
1 x User manual |
Warranty
The warranty period for bicycle is as follows. If the customer finds non-human damage within the warranty period, we will send the replacement parts free of charge.
After warranty period, the customer has to pay replacement parts and shipping fees. The bike which we sell are factory new regular products, all parts are the same as the original parts.
WARRANTY COVERAGE
|
Accessory
|
Warranty period
|
Fault evidence
|
Information provide
|
|
Electrical Accessories
|
|
Battery
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Motor
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Controller
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Charger
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Display
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Shift lever
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Light
|
6 months
|
Video/photo/description
|
Order number/product model and color
|
|
Hardware
|
|
Frame
|
2 year
|
Video/photo/description
|
Order number/product model and color
|
|
Front fork
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Seat tube
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Handlebars
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Driving system
|
|
Throttle
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Brake Lever
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Braking system
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Chain wheel and crank
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Sprockets
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
Derailleur
|
1 year
|
Video/photo/description
|
Order number/product model and color
|
|
No warranty parts
|
|
Bar end
|
No warranty
|
If there are quality problems in the sign in of no warranty parts, please give feedback within 2 days from the day of customer's sign in, and we will arrange free replacement; Otherwise, the buyer shall purchase at his own expense.
|
|
Cushion
|
No warranty
|
|
Pedal
|
No warranty
|
|
Tyre
|
No warranty
|
|
Fender
|
No warranty
|
|
Paint
|
No warranty
|
|
Decorative strip
|
No warranty
|
DOES NOT QUALIFY FOR WARRANTY:
1. The damage to the vehicle caused by the customer's own modification or the use of non-original accessories is not guaranteed.
2. Damage caused by violence or sabotage is not guaranteed.
3. Damages caused by traffic accidents, natural disasters, and wars are not guaranteed.
4. Damage caused by water ingress or soaking is not guaranteed.
5. If the parts are damaged due to unstable voltage, it will not be guaranteed.
6. Parts and accessories that have passed the warranty (warranty) period are not guaranteed.
7. Failures caused by weight overload are not guaranteed.
8. The failure of the user to use, maintain and maintain in accordance with the manual is not guaranteed.
9. Failure to use in accordance with local laws and regulations will cause failures to be out of warranty.
